Weichai WP4.1NC120-18E220 marine diesel engine

Technical Specification

Features:
  • Make: Weichai
  • Model code: WP4.1NC120-18E220
  • Series: WP4.1N series
  • Engine speed: 1800 RPM
  • Power output: 88 KW
Read more
Additional info:

High torque reservation Minimum fuel consumption 200g/kW·h Overhaul period of 12000 h Emissions meet IMOⅡ Safe and reliable  Body, cylinder head, piston, bearing and other structural parts of the new design, Weichai Rui power base production Using the global excellent supplier system of Weichai, the quality of parts is reliable Dust-free, constant temperature assembly workshop, high precision test bench Strong power High torque in medium and low speed range, continuous output and strong power Precise control by electronic control unit, high injection pressure and superior acceleration performance 50% rated speed can reach 132% rated torque Economical and fuel-efficient  Adopt high pressure common rail technology, use Bosch fuel system, Weichai independent ECU, precise control of fuel injection volume Minimum fuel consumption rate 200g/kW•h Oil replacement cycle ≥500h Comfortable and environmentally friendly   NVH optimization match, low noise Gear chamber cover, cylinder cover, closed flywheel housing noise reduction design, reduce noise leakage Using electric control multiple injection, greatly reduce vibration and noise Emissions meet the requirements of IMOⅡ  Strong applicability  Optional vibration isolation pad, hand pressure pump and other configurations to meet the needs of different customers Adjust different control strategies according to different performance requirements Receive/output a variety of control signals to meet the requirements of automatic control

Read more
Make Weichai
Manufacturer Weichai Holding Group Co.,Ltd.
Category Ships' equipment and fittings>Prime movers
Model code WP4.1NC120-18E220
Series WP4.1N series
Engine speed 1800 RPM
Power output 88 KW
Type of fuel Diesel
Meets regulations/compliance IMO Ⅱ
Bore (mm) 105 mm
Cylinder configuration / No. of cylinders 4
Engine cycle Four stroke
Additional info
  • High torque reservation
  • Minimum fuel consumption 200g/kW·h
  • Overhaul period of 12000 h
  • Emissions meet IMOⅡ

Safe and reliable

  • Body, cylinder head, piston, bearing and other structural parts of the new design, Weichai Rui power base production
  • Using the global excellent supplier system of Weichai, the quality of parts is reliable
  • Dust-free, constant temperature assembly workshop, high precision test bench

Strong power

  • High torque in medium and low speed range, continuous output and strong power
  • Precise control by electronic control unit, high injection pressure and superior acceleration performance
  • 50% rated speed can reach 132% rated torque

Economical and fuel-efficient

  • Adopt high pressure common rail technology, use Bosch fuel system, Weichai independent ECU, precise control of fuel injection volume
  • Minimum fuel consumption rate 200g/kW•h
  • Oil replacement cycle ≥500h

Comfortable and environmentally friendly

  • NVH optimization match, low noise
  • Gear chamber cover, cylinder cover, closed flywheel housing noise reduction design, reduce noise leakage
  • Using electric control multiple injection, greatly reduce vibration and noise
  • Emissions meet the requirements of IMOⅡ

Strong applicability

  • Optional vibration isolation pad, hand pressure pump and other configurations to meet the needs of different customers
  • Adjust different control strategies according to different performance requirements
  • Receive/output a variety of control signals to meet the requirements of automatic control
