Wärtsilä WST-18R Retractable Thrusters - High performance manoeuvrability and station keeping

Technical Specification

Features:
  • Make: Wärtsilä
  • Model code: WST-18R
  • Application: Wind turbine installation vessels, offshore support vessels, offshore construction vessels, shuttle tankers and heavy lift vessels.
  • Type: Retractable
  • Maximum Power: 2000 KW
Read more
Additional info:

Wärtsilä retractable thrusters have been selected for vessels worldwide, operating in the most demanding environments. Each system from Wärtsilä conforms to the highest performance and reliability standards and are also supported by a worldwide network of service and support workshops. By the 8° tilted propeller gearbox the delivered thrust is more effective, contributing to decarbonisation of station keeping operation. When selecting a dynamic positioning (DP) system Wärtsilä Retractable Thrusters are second to none. With a power ranging between 750 and 6500kW in both L-drive and Z-drive options, there is a solution to suit any operating profile and vessel - including wind turbine installation vessels, offshore support vessels, offshore construction vessels, shuttle tankers and heavy lift vessels. The vertical retraction system minimizes the area footprint in the vessel and enables full retraction that reduces the vessel’s resistance and allows access to shallower waters and ports. The thrusters are controlled by the DP system or from the bridge stations by Wärtsilä ergonomic controls with intuitive touch screen displays providing intuitive management of the entire DP system.

Read more
Make Wärtsilä
Manufacturer Wärtsilä Corporation
Category Ships' equipment and fittings>Thrusters
Model code WST-18R
Application Wind turbine installation vessels, offshore support vessels, offshore construction vessels, shuttle tankers and heavy lift vessels.
Type Retractable
Maximum Power 2000 KW
Input Speed 1000 ~ 1600 RPM
Propeller Diameter 2400 mm
Weight 39000 ~ 43000 Kg
Additional info

Wärtsilä retractable thrusters have been selected for vessels worldwide, operating in the most demanding environments. Each system from Wärtsilä conforms to the highest performance and reliability standards and are also supported by a worldwide network of service and support workshops. By the 8° tilted propeller gearbox the delivered thrust is more effective, contributing to decarbonisation of station keeping operation.

When selecting a dynamic positioning (DP) system Wärtsilä Retractable Thrusters are second to none. With a power ranging between 750 and 6500kW in both L-drive and Z-drive options, there is a solution to suit any operating profile and vessel - including wind turbine installation vessels, offshore support vessels, offshore construction vessels, shuttle tankers and heavy lift vessels.

The vertical retraction system minimizes the area footprint in the vessel and enables full retraction that reduces the vessel’s resistance and allows access to shallower waters and ports. The thrusters are controlled by the DP system or from the bridge stations by Wärtsilä ergonomic controls with intuitive touch screen displays providing intuitive management of the entire DP system.
