Kongsberg Maritime is pleased to announce the launch of two innovative waterjet control systems based on its new JCS (Jet Control System) common technology platform: JCS Compact and JCS Extended.
The use of standardised components across both systems keeps costs down and enhances operational simplicity.
About JCS Compact
JCS Compact is a tailored, closed-loop control system solution designed to manage the steering, reversing bucket and optional interceptor functions on small- to medium-sized waterjets.
It can be used with either one or two control stations and a single waterjet propulsion unit or, for full redundancy and operational safety in the event of unforeseen issues, a dual-waterjet configuration.
Each JCS Compact, complete with waterjet unit and hydraulic components, is factory tested and pre-calibrated before delivery. Its modest dimensions, plug-in assembly and easy-to-follow system start-up instructions make installation and commissioning simple.
System operation
A high-contrast 2.8” display panel provides a visual representation of the steering angle and reversing bucket position In use, the system works together with the waterjet propulsors to provide accurate, smooth and reliable control.
A high-contrast 2.8” display panel provides a visual representation of the steering angle and reversing bucket position and shows informational parameters and alarms, with a variable brightness control to ensure optimal visibility in both direct sunlight and night-time operations.
Functionality
JCS Extended applies the same seamless functionality but on a larger, more advanced scale. Just like its smaller sibling, JCS Extended is used to control waterjet steering, reversing bucket and optional interceptor functions, but can accommodate up to three control stations and four waterjet propulsion units.
Similar to the JCS Compact, the integrated feedback signals provide maximum accuracy in operating the waterjet hydraulic valves. In addition, the Extended system allows for an optional GNSS antenna.
Advanced features
JCS Extended also offers a variety of advanced, built-in optional functions for optimal operational smoothness and stability. Auto Positioning, Anchor Point, Auto Heading and Trim Assist provide optimal craft operability and can lead to lower operational costs in terms of fuel savings. Park Mode enables hydraulic cylinder rods to be withdrawn to prevent fouling when vessels are docked in areas with a high concentration of bio-organisms.
An optional secure remote access solution provides users with Kongsberg servicing support and enhanced alarm traceability
Each control station used with the JCS Extended solution will have its own high-contrast 7” display, with dedicated views providing detailed information for each specific function. On the bridge, design factors such as joystick and armrest integration have been ergonomically updated, while an optional secure remote access solution provides users with high-level Kongsberg servicing support and enhanced alarm traceability.
Meets customer requirements
“These sophisticated but tough new waterjet control systems are constructed with our usual care to ensure top performance even in the most extreme conditions,” says Gunder Norrbygård, Technical Product Manager, Kongsberg Maritime.
“Flexibility is also key, with advanced optional functionalities and the ability for customers to adapt the systems to fulfil their requirements.”
