Danelec Marine DM100 - Sensor Interface Unit (Compact / Modular)

Technical Specification

Features:
  • Make: Danelec Marine
  • Model code: DM100 - Sensor Interface Unit
  • Recording period: 30 days
  • Recording medium: Fixed / Float-free
  • Replay system online / offline: Yes
Read more
Additional info:

8 inputs for serial data (IEC 61162-1, IEC 61162-2 and Modbus) 8 or 16 inputs for analog data 64 inputs for digital data (in compact version) 48 inputs for digital data (in modular version) 1 free slot (in modular version) AC power (110-230V, 50-60Hz)

Read more
Make Danelec Marine
Manufacturer Danelec Marine
Category Navigation, communication and electronics>Voyage data recorders (VDR)
Model code DM100 - Sensor Interface Unit
Recording period 30 days
Recording medium Fixed / Float-free
Replay system online / offline Yes
Standard IMO
Voltage 110 ~ 230 V
Dimension 525 x 342 x 169 (Compact), 525 x 342 x 336 (Modular) mm
Weight 12 (Compact), 23 (Modular) Kg
Additional info
  • 8 inputs for serial data (IEC 61162-1, IEC 61162-2 and Modbus)
  • 8 or 16 inputs for analog data
  • 64 inputs for digital data (in compact version)
  • 48 inputs for digital data (in modular version)
  • 1 free slot (in modular version)
  • AC power (110-230V, 50-60Hz)
