Daphne Technology’s innovative SlipPure™ system has been awarded Approval in Principle (AiP) from Lloyd's Register (“LR”) for its Plasma-Catalytic technology, with LR witnessed results confirming its performance. This recognition marks a significant milestone in the fight against methane slips in the maritime and land-based oil and gas industries.
The advanced SlipPure™ system, which previously received AiP for its plasma-only configuration, now runs its full Plasma-Catalytic process. This advanced technology improves efficiency by lowering plasma power consumption, enabling very high methane slip reductions at exhaust temperatures well below those required for catalyst-only solutions, in Daphne Technology’s view, making it both the most effective and efficient methane slip reduction system available. The SlipPure™ Plasma-Catalysis system is also Approved in Principle by DNV.
Methane slip reduction
Reducing methane emissions is vital as it is liable for at least a quarter of the recent global warming
Methane slip is a major contributor to greenhouse gas emissions, with a global warming potential 28 times greater than that of CO2 over a 100-year period. Reducing methane emissions is crucial as it is responsible for at least a quarter of the current global warming. As it has a much shorter atmospheric lifetime compared to CO2, cutting methane emissions now can lead to faster climate benefits.
Daphne Technology believes it is the only company actively developing a Plasma-Catalysis system for methane slip reduction. This advanced system integrates the patented wavelet pulse power (WPP) supply technology to generate plasma and utilises the proprietary catalyst, ensuring unmatched performance and efficiency.
Plasma-Catalytic process
SlipPure™ has undergone several rigorous test campaigns utilising exhaust gas produced from a land-based test engine (746 kW lean burn spark ignited engine type RR MTU 8V4000M55RN) installed at the Maritime Centre of the University of Applied Science in Flensburg, Germany.
The Plasma-Catalytic process was evaluated over nearly 100 h of operation
In January 2023, safe operation of the WPP power supply in the plasma-only system was demonstrated over nearly 75 hours of operation. Earlier this year, the Plasma-Catalytic process was evaluated over nearly 100 hours of operation, and LR witnessed 4.0 g/kWh removal of methane slip (62% methane slip reduction at 75% load) from exhaust gas with temperatures as low as 380°C.
Reducing methane emissions
"We are again very honoured to be working closely with Lloyd's Register and delighted to receive this AiP," said Dr. Mario Michan, CEO and Founder of Daphne Technology. "This approval in principle validates our innovative approach, and the witnessed results are a testament to the efficacy and reliability of our SlipPure™ system. The performance results demonstrate our technology's readiness for market deployment and its impact on reducing methane emissions."
Panos Mitrou, Lloyd's Register Global Gas Segment Director, said: “LR has been working with Daphne Technology for several years and following recent testing, it’s clear that its Plasma-Catalytic technology is moving the bar in helping companies to meaningfully mitigate methane slip in the maritime and land-based oil and gas industries.”
Key Benefits of the SlipPure™ Plasma-Catalysis System
- Reduced Power Consumption: More energy-efficient compared to plasma-only systems.
- Feasibility: Operates effectively at the lower exhaust temperatures typical of marine engines.
- Innovative Technology: Combines the strengths of plasma and catalysis for superior methane abatement.
Reporting of GHG emissions
SlipPure™ with Daphne Technology's PureMetrics™ improves the point of methane slip drop
The Plasma-Catalysis system represents a breakthrough in methane abatement technology, significantly enhancing the efficacy of SlipPure™ while reducing power consumption and maintaining operational feasibility.
Additionally, combining SlipPure™ with Daphne Technology's PureMetrics™ enhances the effectiveness of methane slip reduction by providing accurate quantification and reporting of GHG emissions. PureMetrics™ is essential for monitoring the real-time impact of SlipPure™, offering auditable reports and operational insights.
Next version of SlipPure™
This integration ensures compliance with environmental regulations and helps companies achieve their sustainability goals by providing a clear picture of their emissions.
The next version of SlipPure™ is currently being manufactured for deployment in November 2024 with a US Oil super-major, highlighting the commitment to continuous improvement and market readiness.
