ABB NXR 400MK4 Multipurpose Rib Cooled Motors (type NXR)

Technical Specification

Features:

Make: ABB
Model code: NXR 400MK4
Series: Rib cooled motors, type NXR
Type: Induction
Output Power: 710 kW

Additional info:

Available for variable speed drives (VSD), and thus allowing even higher energy savings Safe operation in even the harshest of conditions - high protection level, IP class up to IP66 Safe area motors can be equipped with digital Smart Sensor, allowing easy access to motor main characteristics Optimized and effective cooling allow longer lifetime for bearings and longer lubrication intervals Built-in configurability enables shorter delivery times Built-in serviceability enables efficient maintenance reducing downtime and costs

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	ABB
Manufacturer	ABB
Category	Ships' equipment and fittings>Motors
Model code	NXR 400MK4
Series	Rib cooled motors, type NXR
Type	Induction
Output Power	710 kW
Rotational speed	1500 RPM
Approvals	IEC, NEMA
Insulation class	F
Construction	Cast iron
Voltage	6000 V
Frequency	50 Hz
Max. Torque	4557 Nm
Protection class	IP55 (optionally IP56, IP65 and IP66)
Weight	3490 Kg
Additional info	Available for variable speed drives (VSD), and thus allowing even higher energy savings Safe operation in even the harshest of conditions - high protection level, IP class up to IP66 Safe area motors can be equipped with digital Smart Sensor, allowing easy access to motor main characteristics Optimized and effective cooling allow longer lifetime for bearings and longer lubrication intervals Built-in configurability enables shorter delivery times Built-in serviceability enables efficient maintenance reducing downtime and costs
